22
Load PRESET
This menu page allows the required PRESET to be loaded and made operative.
Load Preset
2U 2x2W
To load a PRESET:
☞ Use the DIAL to reach the required PRESET.
21 Factory PRESETS and 32 User PRESETS.
N.B.: since the system must always be configured, there are no empty memory areas. All the User areas not yet used
by custom PRESETS are automatically occupied by the *Default* PRESET, which contains a standard start configuration
with all the values of the various parameters at zero.
Load Preset
32U *Default*
A13 B24
32U *Default*
☞ Press ENTER.
The system returns to default status and the display shows the information on the PRESET that has
just been loaded.
A1 B2 S34
3F 2W+MSB+MAX
N.B.: in the example, Factory PRESET #3, named “2W+MSB+MAX” has been loaded: its system configuration is Input
A signal assigned to output 1, Input B signal assigned to output and the Sum of Input A and Input B signal assigned
to outputs 3 and 4.
Loading a Preset, a Program Change command could also automatically be sent to the MIDI OUT
port and can be used to automatically load a PRESET with the same number to any other DX 24
units connected and enabled (see UTILITY menu - Midi Setup submenu - MIDI PrgCh Out and
MIDI PrgCh In options).
