LEM DX 24 - Output Delay Adjustment

27
Output Delay
This menu page allows to adjust the delay lines of outputs 1, 2, 3 and 4.
Ò
Out
p
ut Dela
y
The values can be set in the following ranges:
OP1 DELAY
292
µ
s
unit step
m 0.0 ÷ 65.0 0.5
mm 0 ÷ 65000 7
ms 0 ÷ 189 1
m
s
0 ÷ 189333 21
OUTPUT DELAY
ran
g
e
The measurement unit can be chosen with the function Delay Unit (UTILITY menu - Units submenu).
18ms
(6,5m)
OP1 DELAY =
0ms
14ms
(5m)
OUTPUT DELAY
OUTPUT 1
HIGH
OUTPUT 3
LOW
OP3 DELAY =
4ms
4ms
Loudspeaker
Components
Delayed Virtual
Ali
g
nment #2
OUTPUT DELAY
Delayed Virtual
Ali
g
nment #1
DELAY Menu
