LEM DX 24 - Input Delay Adjustment

26
Input Delay
This menu page allows to adjust the delay lines of Input A, Input B and SUM.
Ò
In
p
ut Dela
y
The values can be set in the following ranges:
INA DELAY
77ms
unit step
m 0.0 ÷ 200.0 0.5
mm 0 ÷ 200000 7
ms 0 ÷ 582 1
m
s
0 ÷ 582542 21
INPUT DELAY
ran
g
e
The measurement unit can be chosen with the function Delay Unit (UTILITY menu - Units submenu).
INPUT DELAY
INPUT A
MAIN PA
91ms - 31,5m
(20°C)
INB DELAY = 91msINA DELAY = 0
INPUT B
DELAYED
DELAY Menu
