15
Number of PRESETS
A12B3S4
4U 3W+BSB+MAX
Number of PRESET
17 Factory PRESETS and 32 User PRESETS are available.
Type of PRESET
A12B3S4
4U 3W+BSB+MAX
Type of PRESET
There are 2 categories of PRESETS:
F = Factory PRESETS factory programmed, cannot be permanently changed.
These include all the system’s usable configurations + some specific setups
for LEM enclosures.
These are the starting points for creating User PRESETS from scratch.
U = User PRESETS can be programmed by users.
Name of the PRESET
A12B3S4
4U 3W+BSB+MAX
Name of the PRESET
In the example, the name indicates a two-way stereo system + two auxiliary mono outputs.
N.B.: the name of a Factory PRESET normally indicates the general structure of the sound system to be connected
to the DX 24 or of a specific speaker enclosure model.
The name of a User PRESET can be edited as required. For example:
A12B3S4
4U M
