56
Technical Specifications
Connectors 2 x XLR-F
Nominal input sensitivity 0 dB (0.775 V)
Input Impedance 30kOhm, electronically balanced
Maximum Input Level +14dBu
Input Gain -30 / +6 dB variable in 0.5 dB steps
Connectors 4 x XLR-M
Output Impedance 600 Ohms, electronically balanced
Nominal Output Level 0 dBu
Maximum Output Level +14 dBu
Output Gain -30 / +6 dB variable in 0.5 dB steps
A/D converters 20 bit
D/A converters 24 bit
Internal dynamics 40 bit
Sampling frequency 48 kHz
Configuration 2-WAY STEREO, 2,3,4-WAY MONO
Crossover Filters Type Bessel, Butterworth or Linkwitz-Riley
Crossover Filters Slope 6, 12, 18, 24, or 48dB per octave
Delay Step 21 microseconds minimum
Max Delay time 582 ms (inputs), 189 ms (outputs)
EQ filters Up to 30 maximum (depending on the crossover slope)
EQ Type Peak, 6dB Lo-Shelf, 12dB Lo-Shelf, 6dB Hi-Shelf, 12dB Lo-Shelf, Notch
EQ Gain +/15dB, variable in 0.5dB steps
EQ Bandwidth 0.05 to 3.00 octaves, variable in 0.05 steps
EQ freq 15.6 Hz to 16 kHz
Dynamics Digital limiter on all the outputs
Memories 17 FACTORY PRESETS + 32 USER PRESETS
MIDI MIDI IN/THRU/OUT
Frequency Response 20Hz - 20kHz, ±0.25dB
Dynamic range >102dB 20Hz to 20kHz
Channel Separation >100dB 20Hz to 20kHz
Distortion (THD) 0.06% , 20Hz to 20kHz
Input Metering -24dB, -18dB, -12dB, -6dB, CLIP relative to Clip point (+14dBu)
Output Metering -24dB, -12dB, -6dB, LIMIT relative to limiter threshold setting, CLIP
Dimensions 483x44x300 mm
Weight 4.0 Kg
Power supply see label on the unit
General
DSP Section
INPUT section
Output Section
Features
General Performance (with filters out)
Technical Specifications
