LEM DX 24 - Factory PRESETS

55
Factory PRESETS
# Name Configuration Description Amplifiers
01 DEFAULT A13 B24 Default preset - routing = 2-WAY STEREO -
02 2X2W A13 B24 2-WAY STEREO -
03 2X2W+MSB+MAX A1 B2 S34 2-WAY STEREO + MONO SUB + 1 MONO FULL-RANGE OUT -
04 3W+BSB+MAX A12 B3 S4 3-WAY MONO with B-SUB + 1 MONO FULL-RANGE OUT -
05 4W+BSB A123 B4 4-WAY MONO with B-SUB -
06 4W A1234 4-WAY MONO -
07 K6 A13 B24 1 x K6 (for each side)
PFC3 (75W/8ohm)
PFC5 (500W/8ohm)
08 K6+KL A1234 1 x K6 + 1 x KL (MONO)
PFC3 (75W/8ohm)
PFC5 (500W/8ohm)
PFC5 (600W/8ohm)
09 K6+2xKL A1234 1 x K6 + 2 x KL (MONO)
PFC3 (75W/8ohm)
PFC5 (500W/8ohm)
PFC5 (1200W/4ohm)
10 K3 A13 B24 1 x K3 (for each side)
PFC3 (50W/8ohm)
PFC3 (300W/8ohm)
11 K3+KL A1234 1 x K3 + 1 x KL (MONO)
PFC3 (50W/8ohm)
PFC3 (300W/8ohm)
PFC5 (600W/8ohm)
12 TM18 PR A1234 1 x TM18.3 MH + 1 x TM18.3 L (MONO)
PFC3 (90W/8ohm)
PFC3 (250W/8ohm)
PFC5 (1500W/4ohm)
13 TM18 FL A1234 1 x TM18.3 MH + 1 x TM18.3 L (MONO)
PFC3 (90W/8ohm)
PFC3 (250W/8ohm)
PFC5 (1500W/4ohm)
14 TM15 PR A13 B24 1 x TM 15.2 (for each side)
PFC3 (90W/8ohm)
PFC5 (800W/8ohm)
15 TM15 FL A13 B24 1 x TM 15.2 (for each side)
PFC3 (90W/8ohm)
PFC5 (800W/8ohm)
16 TM15+18 PR A1234 2 x TM15.2 + 1 x TM18.3 L (MONO)
PFC3 (180W/4ohm)
PFC3 (1500W/4ohm)
PFC5 (1500W/4ohm)
17 TM15+18 FL A1234 2 x TM15.2 + 1 x TM18.3 L (MONO)
PFC3 (180W/4ohm)
PFC3 (1500W/4ohm)
PFC5 (1500W/4ohm)
+ IMPORTANT NOTE
The OUTPUT LEVEL and LIMITER THRESHOLD settings of the FACTORY PRESETS for LEM
enclosures have been made considering the OUTPUT POWER and INPUT SENSITIVITY
specifications of the LEM POWERFACTOR amplifiers in the CONSTANT GAIN (26dB) configuration.
Therefore, if amplifiers with different specifications are used, these parameters need to be
consequently adjusted.
