Preparation of the Tractor
35
Tractor output
kW HP
Cat. Pintle diameter of draw
rail (mm)
Length of draw rail
(shoulder distance) (mm)
80 - 185 109 - 251 3N 36,6 825
80 - 185 109 - 251 3 36,6 965
150 - 350 204 - 476 4N 50,8 965
150 - 350 204 - 476 4 50,8 1166
DANGER
Danger to life if a three-point linkage is used with a too small
category
If a draw rail or a top link pin is used with a category that is too
small, these components may be overloaded and break. As a re-
sult, the implement may fall down and injure or kill people in the
immediate vicinity.
As a result, the implement may be damaged.
As a result, other road users may be injured or killed while the im-
plement is being transported.
Use only draw rails and top link pins which comply with a cate-
gory that corresponds to the tractor's output in accordance with
ISO 730-1.
