LEMKEN Karat 9 - Rollers; General Information

Adjustments
58
9.8 Rollers
9.8.1 General information
The mounted devices can be fitted with different roller types, see the following
roller table. The rollers control the device at the working depth. Irrespective of the
roller type used, the soil is more or less re-consolidated or more or less crumbled.
Roller type
Mounted devices
Karat 9 U
Mounted devices
Karat 9 U
RSW 400 x x Tube bar roller
RSW 540 x x
DRF 400 x x Double rollers
DRR 400 x x
Blade roller MSW 600 x x
The tube bar rollers and double rollers do not require any special adjustment
measures.
The blade roller features a knife bar with blades used as scrapers which are highly
adjustable, see section entitled "Blade roller".
