SPECIFICATIONS - DIRECT DRIVE BLOWER 3 TON | 4 TON
General Data Nominal Tonnage 3 Ton 3 Ton 4 Ton 4 Ton
Model No. KGB036S4E KGB036S4D KGB048S4E KGB048S4D
Eciency Type Standard Standard Standard Standard
Blower Type Multi-Speed
Direct Drive
ECM
Multi-Speed
Direct Drive
PSC
Multi-Speed
Direct Drive
ECM
Multi-Speed
Direct Drive
PSC
Cooling
Performance
1
1150 1150 1560 1560
2
Sound Rating Number (dBA) 74 74 74 74
2.9 2.9 4.1 4.1
1
14.0 14.0 14.0 14.0
1
12.3 12.3 11.5 11.5
Refrigerant
Refrigerant Type R-410A R-410A R-410A R-410A
Environ™ Coil System 5 lbs. 9 oz. 5 lbs. 9 oz. 5 lbs. 10 oz. 5 lbs. 10 oz.
Conventional Fin/Tube Coil 11 lbs. 3 oz. 11 lbs. 3 oz. 9 lbs. 13 oz. 9 lbs. 13 oz.
Humiditrol
®
12 lbs. 7 oz. 12 lbs. 7 oz. 9 lbs. 13 oz. 9 lbs. 13 oz.
Gas Heating Options
Standard (1 or 2 Stage)
Medium (1 or 2 Stage)
Standard (1 or 2 Stage)
Medium (1 or 2 Stage)
High (1 or 2 Stage)
Compressor Type (one per unit) Scroll Scroll Scroll Scroll
Outdoor Coil
Environ™
(Fin/Tube)
Net face area - sq. ft. 14.5 (15.6) 14.5 (15.6) 14.5 (15.6) 14.5 (15.6)
1 (2) 1 (2) 1 (2) 1 (2)
23 (20) 23 (20) 23 (20) 23 (20)
Outdoor
Coil Fan
Motor - (No.) HP (1) 1/4 (1) 1/4 (1) 1/4 (1) 1/4
Motor rpm 825 825 825 825
325 325 325 325
Diameter - (No.) in. / No. of blades (1) 24 - 4 (1) 24 - 4 (1) 24 - 4 (1) 24 - 4
Total air volume - cfm 3950 3950 3950 3950
Indoor Coil Net face area - sq. ft. 7.8 7.8 7.8 7.8
Tube diameter - in. 3/8 3/8 3/8 3/8
3 3 3 3
14 14 14 14
Drain Connection (no.) and size - in. (1) 1 NPT (1) 1 NPT (1) 1 NPT (1) 1 NPT
Expansion device type
Indoor
Nominal Motor HP
(1) 10 x 10 (1) 10 x 10 (1) 10 x 10 (1) 10 x 10
Filters Type Disposable
Number and size - in. (4) 16 x 20 x 2
208/230V
460V & 575V
208/230V
460V & 575V
1
2
