Page 31
ELECTRICAL DATA DIRECT DRIVE ECM - 2 TON | 2.5 TON ECM
Model No. KGB024S4E KGB030S4E
1
208/230V - 1 Ph 208/230V - 1 Ph
Compressor Rated Load Amps 10.9 13.5
Locked Rotor Amps 60 73
Outdoor Fan
Motor
Full Load Amps 1.7 1.7
Service Outlet 115V GFI (amps) 15 15
Motor
0.33 0.33
Type Direct (ECM) Direct (ECM)
Full Load Amps 2.9 2.9
2
Maximum
Overcurrent
Protection
Unit Only 25 30
3
Minimum
Circuit
Ampacity
Unit Only 19 22
ELECTRICAL ACCESSORIES
Disconnect Standard Access 20W17 20W17
Hinged Access 20W23 20W23
1
Extremes of operating range are plus and minus 10% of line voltage.
2
HACR type breaker or fuse.
3
ELECTRICAL DATA DIRECT DRIVE ECM - 3 TON | 4 TON | 5 TON
Model No. KGB036S4E KGB048S4E KGB060S4E
1
208/230V - 1 Ph 208/230V - 1 Ph 208/230V - 1 Ph
Compressor Rated Load Amps 15.3 20 24.4
Locked Rotor Amps 70 99 144
Outdoor Fan
Motor
Full Load Amps 1.7 1.7 1.65
(1) 0.33 HP
Full Load Amps 2.4 2.4 2.4
Service Outlet 115V GFI (amps) 15 15 15
Motor
0.50 0.75 1.0
Type Direct (ECM) Direct (ECM) Direct (ECM)
Full Load Amps 4.6 6.3 8.4
2
Maximum
Overcurrent
Protection
Unit Only 40 50 60
40 50 60
3
Minimum
Circuit
Ampacity
Unit Only 26 33 41
28 36 43
ELECTRICAL ACCESSORIES
Disconnect Standard Access 20W17 20W17 20W20
Hinged Access 20W23 20W23 20W26
1
Extremes of operating range are plus and minus 10% of line voltage.
2
HACR type breaker or fuse.
3
