Page 32
ELECTRICAL DATA DIRECT DRIVE PSC - 4 TON
KGB048S4D - STANDARD EFFICIENCY - DIRECT DRIVE PSC BLOWER
1
208/230V - 3 Ph 460V - 3 Ph 575V - 3 Ph
Compressor Rated Load Amps 11 5.5 4.7
Locked Rotor Amps 86 37 34
Outdoor Fan
Motor
Full Load Amps 1.7 1.1 0.7
(1) 0.33 HP
Full Load Amps 2.4 1.3 1
Service Outlet 115V GFI (amps) 15 1.3 1
Motor
0.5 0.5 0.5
Type Direct (PSC) Direct (PSC) Direct (PSC)
Full Load Amps 3.9 2 2
2
Maximum
Overcurrent
Protection
Unit Only 30 15 15
30 15 15
3
Minimum
Circuit
Ampacity
Unit Only 20 10 9
22 12 10
ELECTRICAL ACCESSORIES
Disconnect Standard Access 20W17 20W17 20W17
Hinged Access 20W23 20W23 20W23
1
Extremes of operating range are plus and minus 10% of line voltage.
2
HACR type breaker or fuse.
3
ELECTRICAL DATA DIRECT DRIVE PSC - 3 TON
Model No. KGB036S4D
1
208/230V - 3 Ph 460V - 3 Ph 575V - 3 Ph
Compressor Rated Load Amps 8.7 4 3.6
Locked Rotor Amps 70 31 27
Outdoor Fan
Motor
Full Load Amps 1.7 1.1 0.7
(1) 0.33 HP
Full Load Amps 2.4 1.3 1
Service Outlet 115V GFI (amps) 15 15 20
Motor
0.5 0.5 0.5
Type Direct (PSC) Direct (PSC) Direct (PSC)
Full Load Amps 3.9 2 2
2
Maximum
Overcurrent
Protection
Unit Only 25 15 15
25 15 15
3
Minimum
Circuit
Ampacity
Unit Only 17 9 8
19 10 9
ELECTRICAL ACCESSORIES
Disconnect Standard Access 20W17 20W17 20W17
Hinged Access 20W23 20W23 20W23
1
Extremes of operating range are plus and minus 10% of line voltage.
2
HACR type breaker or fuse.
3
