Page 14
BLOWER DATA DIRECT DRIVE ECM - 2 TON | 2.5 TON
KGB024S4E | KGB030S4E
BLOWER TABLE INCLUDES RESISTANCE FOR BASE UNIT ONLY WITH DRY INDOOR COIL AND AIR FILTERS IN PLACE.
External
Static
Press.
in. w.g.
Air Volume (cfm) at Various Blower Speeds
Blower Only Low Speed High Speed Free Cooling
Low and High Speed:
G (Pin 1)
Cooling:
Y1 (Pin 2 and 5)
1st Stage Heating:
W1 (Pin 2)
2nd Stage Heating:
W2 (Pin 2 and 4)
1st Stage Heating:
W1 (Pin 3)
2nd Stage Heating:
W2 (Pin 3 and 4)
Cooling:
Y1 (Pin 3 and 5)
Low and High Speed:
Y1 (Pin 1 and 5)
0 488 985 1127 1353 1127 1127
0.1 421 913 1082 1311 1082 1082
0.2 333 841 1037 1269 1037 1037
0.3 285 754 988 1224 988 988
0.4 215 668 923 1180 923 923
0.5 - - - 611 858 1135 858 858
0.6 - - - 553 809 1076 809 809
0.7 - - - 481 760 1017 760 760
0.8 - - - - - - 694 972 694 694
0.9 - - - - - - 646 928 646 646
1.0 - - - - - - 580 869 580 580
HORIZONTAL
External
Static
Press.
in. w.g.
Air Volume (cfm) at Various Blower Speeds
Blower Only Low Speed High Speed Free Cooling
Low and High Speed:
G (Pin 1)
Cooling:
Y1 (Pin 2 and 5)
1st Stage Heating:
W1 (Pin 2)
2nd Stage Heating:
W2 (Pin 2 and 4)
1st Stage Heating:
W1 (Pin 3)
2nd Stage Heating:
W2 (Pin 3 and 4)
Cooling:
Y1 (Pin 3 and 5)
Low and High Speed:
Y1 (Pin 1 and 5)
0 479 965 1104 1326 1104 1104
0.1 412 895 1060 1285 1060 1060
0.2 326 824 1016 1244 1016 1016
0.3 280 739 968 1200 968 968
0.4 211 655 905 1156 905 905
0.5 - - - 599 841 1112 841 841
0.6 - - - 542 793 1054 793 793
0.7 - - - 471 745 997 745 745
0.8 - - - - - - 680 953 680 680
0.9 - - - - - - 633 909 633 633
1.0 - - - - - - 568 852 568 568
