Page 15
BLOWER DATA DIRECT DRIVE ECM - 3 TON
KGB036S4E
BLOWER TABLE INCLUDES RESISTANCE FOR BASE UNIT ONLY WITH DRY INDOOR COIL AND AIR FILTERS IN PLACE.
External
Static
Press.
in. w.g.
Air Volume (cfm) at Various Blower Speeds
Blower Only Low Speed High Speed Free Cooling
Low and High
Speed:
G (Pin 1)
1st Stage Heating:
W1 (Pin 2)
Cooling:
Y1 (Pin 2 and 5)
2nd Stage
Heating:
W2 (Pin 2 and 4)
1st Stage
Heating:
W1 (Pin 3)
2nd Stage
Heating:
W2 (Pin 3 and 4)
Cooling:
Y1 (Pin 3 and 5)
Low and High
Speed:
Y1 (Pin 1 and 5)
0 862 1375 1567 1706 1840 1567 1567
0.1 809 1330 1539 1682 1780 1539 1539
0.2 741 1277 1511 1658 1748 1511 1511
0.3 680 1253 1477 1624 1712 1477 1477
0.4 622 1200 1443 1598 1677 1443 1443
0.5 555 1150 1409 1564 1638 1409 1409
0.6 - - - 1095 1364 1530 1608 1364 1364
0.7 - - - 1052 1330 1496 1577 1330 1330
0.8 - - - 1004 1296 1444 1528 1296 1296
0.9 - - - 950 1251 1419 1491 1251 1251
1.0 - - - 900 1206 1394 1455 1206 1206
HORIZONTAL
External
Static
Press.
in. w.g.
Air Volume (cfm) at Various Blower Speeds
Blower Only Low Speed High Speed Free Cooling
Low and High
Speed:
G (Pin 1)
1st Stage Heating:
W1 (Pin 2)
Cooling:
Y1 (Pin 2 and 5)
2nd Stage
Heating:
W2 (Pin 2 and 4)
1st Stage
Heating:
W1 (Pin 3)
2nd Stage
Heating:
W2 (Pin 3 and 4)
Cooling:
Y1 (Pin 3 and 5)
Low and High
Speed:
Y1 (Pin 1 and 5)
0 479 1379 1536 1672 1810 1536 1536
0.1 412 1305 1508 1648 1749 1508 1508
0.2 326 1264 1481 1625 1718 1481 1481
0.3 280 1216 1447 1592 1677 1447 1447
0.4 211 1173 1414 1566 1649 1414 1414
0.5 - - - 1131 1381 1533 1622 1381 1381
0.6 - - - 1078 1337 1499 1577 1337 1337
0.7 - - - 1038 1303 1466 1544 1303 1303
0.8 - - - 986 1270 1415 1509 1270 1270
0.9 - - - 933 1226 1391 1471 1226 1226
1.0 - - - 885 1182 1366 1438 1182 1182
