Page 16
BLOWER DATA DIRECT DRIVE ECM - 4 TON
KGB048S4E
BLOWER TABLE INCLUDES RESISTANCE FOR BASE UNIT ONLY WITH DRY INDOOR COIL AND AIR FILTERS IN PLACE.
External
Static
Press.
in. w.g.
Air Volume (cfm) at Various Blower Speeds
Blower Only Low Speed High Speed Free Cooling
Low and High Speed:
G (Pin 1)
Cooling:
Y1 (Pin 2 and 5)
1st Stage Heating:
W1 (Pin 2)
2nd Stage Heating:
W2 (Pin 2 and 4)
2nd Stage Heating:
W2 (Pin 3 and 4)
1st Stage Heating:
W1 (Pin 3)
Cooling:
Y1 (Pin 3 and 5)
Low and High Speed:
Y1 (Pin 1 and 5)
0 963 1561 1869 2156 1869 1958
0.1 897 1530 1842 2132 1842 1920
0.2 831 1499 1815 2108 1815 1882
0.3 752 1466 1788 2084 1788 1844
0.4 673 1432 1750 2057 1750 1814
0.5 620 1398 1723 2031 1723 1784
0.6 567 1353 1695 1991 1695 1754
0.7 501 1319 1658 1952 1658 1724
0.8 - - - 1274 1621 1899 1621 1694
0.9 - - - 1240 1593 1794 1593 1672
1.0 - - - 1184 1556 1689 1556 1650
HORIZONTAL
External
Static
Press.
in. w.g.
Air Volume (cfm) at Various Blower Speeds
Blower Only Low Speed High Speed Free Cooling
Low and High Speed:
G (Pin 1)
Cooling:
Y1 (Pin 2 and 5)
1st Stage Heating:
W1 (Pin 2)
2nd Stage Heating:
W2 (Pin 2 and 4)
2nd Stage Heating:
W2 (Pin 3 and 4)
1st Stage Heating:
W1 (Pin 3)
Cooling:
Y1 (Pin 3 and 5)
Low and High Speed:
Y1 (Pin 1 and 5)
0 944 1530 1832 2113 1832 1919
0.1 879 1499 1805 2089 1805 1882
0.2 814 1469 1779 2066 1779 1844
0.3 737 1437 1752 2042 1752 1807
0.4 660 1403 1715 2016 1715 1778
0.5 608 1370 1689 1990 1689 1748
0.6 556 1326 1661 1951 1661 1719
0.7 491 1293 1625 1913 1625 1690
0.8 - - - 1249 1589 1861 1589 1660
0.9 - - - 1215 1561 1758 1561 1639
1.0 - - - 1160 1525 1655 1525 1617
