Page 17
BLOWER DATA DIRECT DRIVE ECM - 5 TON
KGB060S4E
BLOWER TABLE INCLUDES RESISTANCE FOR BASE UNIT ONLY WITH DRY INDOOR COIL AND AIR FILTERS IN PLACE.
External
Static
Press.
in. w.g.
Air Volume (cfm) at Various Blower Speeds
Blower Only Low Speed High Speed Free Cooling
Low and High
Speed:
G (Pin 1)
1st Stage Heating:
W1 (Pin 2)
Cooling:
Y1 (Pin 2 and 5)
2nd Stage
Heating:
W2 (Pin 2 and 4)
1st Stage
Heating:
W1 (Pin 3)
2nd Stage
Heating:
W2 (Pin 3 and 4)
Cooling:
Y1 (Pin 3 and 5)
Low and High
Speed:
Y1 (Pin 1 and 5)
0 1088 1801 1982 1801 2339 2287 2287
0.1 1042 1769 1956 1769 2310 2251 2251
0.2 996 1736 1928 1736 2281 2215 2215
0.3 948 1703 1900 1703 2253 2178 2178
0.4 883 1669 1870 1669 2224 2142 2142
0.5 835 1634 1838 1634 2195 2106 2106
0.6 787 1598 1806 1598 2166 2058 2058
0.7 723 1561 1772 1561 2137 2010 2010
0.8 658 1524 1736 1524 2108 1937 1937
0.9 594 1486 1700 1486 2080 1841 1841
1.0 546 1446 1662 1446 2051 1696 1696
HORIZONTAL
External
Static
Press.
in. w.g.
Air Volume (cfm) at Various Blower Speeds
Blower Only Low Speed High Speed Free Cooling
Low and High
Speed:
G (Pin 1)
1st Stage Heating:
W1 (Pin 2)
Cooling:
Y1 (Pin 2 and 5)
2nd Stage
Heating:
W2 (Pin 2 and 4)
1st Stage
Heating:
W1 (Pin 3)
2nd Stage
Heating:
W2 (Pin 3 and 4)
Cooling:
Y1 (Pin 3 and 5)
Low and High
Speed:
Y1 (Pin 1 and 5)
0 1066 1728 1886 1728 2206 2241 2241
0.1 1021 1708 1872 1708 2189 2206 2206
0.2 976 1685 1859 1685 2174 2171 2171
0.3 929 1661 1832 1661 2157 2134 2134
0.4 865 1636 1814 1636 2135 2099 2099
0.5 818 1608 1796 1608 2118 2064 2064
0.6 771 1579 1770 1579 2102 2017 2017
0.7 709 1548 1743 1548 2080 1970 1970
0.8 645 1516 1716 1516 2058 1898 1898
0.9 582 1481 1689 1481 2036 1804 1804
1.0 535 1445 1654 1445 2020 1662 1662
