SPECIFICATIONS - BELT DRIVE BLOWER SINGLE SPEED - 3 TON | 4 TON | 5 TON
General Data Nominal Tonnage 3 Ton 4 Ton 5 Ton
Model No. KGB036S4B KGB048S4B KGB060S4B
Eciency Type Standard Standard Standard
Blower Type Single Speed
Belt Drive
Single Speed
Belt Drive
Single Speed
Belt Drive
Cooling
Performance
1
1150 1560 1760
2
Sound Rating Number (dBA) 74 74 83
2.9 4.1 5
1
14.0 14.0 14.0
1
12.3 11.5 11.0
Refrigerant
Refrigerant Type R-410A R-410A R-410A
Environ™ Coil System 5 lbs. 9 oz. 5 lbs. 10 oz. 8 lbs. 0 oz.
Conventional Fin/Tube Coil 11 lbs. 3 oz. 9 lbs. 13 oz. 14 lbs. 3 oz.
Humiditrol
®
12 lbs. 7 oz. 9 lbs. 13 oz. 15 lbs. 3 oz.
Gas Heating Options
Standard (1 or 2 Stage)
Medium (1 or 2 Stage)
Standard (1 or 2 Stage)
Medium (1 or 2 Stage)
High (1 or 2 Stage)
Compressor Type (one per unit) Scroll Scroll Scroll
Outdoor Coil
Environ™
(Fin/Tube)
Net face area - sq. ft. 14.5 (15.6) 14.5 (15.6) 17.8 (19.3)
1 (2) 1 (2) 1 (2)
23 (20) 23 (20) 23 (20)
Outdoor
Coil Fan
Motor - (No.) HP (1) 1/4 (1) 1/4 (1) 1/3
Motor rpm 825 825 1075
325 325 375
Diameter - (No.) in. / No. of blades (1) 24 - 4 (1) 24 - 4 (1) 24 - 3
Total air volume - cfm 3950 3950 4700
Indoor Coil Net face area - sq. ft. 7.8 7.8 9.7
Tube diameter - in. 3/8 3/8 3/8
3 3 4
14 14 14
Drain Connection (no.) and size - in. (1) 1 NPT (1) 1 NPT (1) 1 NPT
Expansion device type
3
Indoor
Selection
Nominal Motor HP
Maximum Usable Motor Output (US Only)
Available Drive Kits A01
673 - 1010 rpm
A05
897 - 1346 rpm
A02
745 - 1117 rpm
A06
1071 - 1429 rpm
A03
833 - 1250 rpm
A07
1212 - 1548 rpm
(1) 10 x 10 (1) 10 x 10 (1) 10 x 10
Filters Type Disposable
Number and size - in. (4) 16 x 20 x 2 (4) 20 x 20 x 2
1
2
3
