a.Oneachsideoftheserver,insertthesignalcableoftherackhandleintothehole1inthechassis
andthenpushthesignalcablethroughtheholeintothechassis.Whenthesignalcableisprotruding
fromthecrackbetweenthesideedgeofthebackplaneandtheinnersideofthechassis,holdthe
signalcablefromtherearandcarefullypullitintothechassisuntilitisstoppedbytherackhandle.
b.Insertthetwosmalltabsontherackhandleintothecorrespondingholes2inthechassis.Ensure
thatthescrewholeintherackhandleisalignedwiththecorrespondinghole3inthechassis.Then,
installthescrewtosecuretherackhandleoneachsideoftheserver.
Figure49.Installingtherackhandles
Chapter6.Installing,removing,orreplacinghardware95
