Lenovo ThinkServer RS160 User Manual

Forservicetechnicianonly:replacingthesystemboard
CAUTION:
Hazardousmovingparts.Keepfingersandotherbodypartsaway.
CAUTION:
Theheatsinkandmicroprocessormightbeveryhot.Turnofftheserverandwaitseveralminutesto
lettheservercoolbeforeremovingtheservercover.
Toreplacethesystemboard,dothefollowing:
1.Prepareyourserver.See“Preparingyourserverinadvance”onpage47.
2.Recordthecomponentlocations,cableconnections,andcableroutingintheserver.Then,disconnect
allcablesfromthesystemboard.
3.Toaccessthesystemboard,removethefollowingcomponentsinorder:
a.“Removingtheairbaffle”onpage50
b.“Removingtheheatsink”onpage52
c.“Removingthememorymodule”onpage54
d.“RemovingthePCIecard”onpage56
e.“Removingtherisercard”onpage58
f.“RemovingtheTPM”onpage80
g.“Removingthecoin-cellbattery”onpage83
92ThinkServerRS160UserGuideandHardwareMaintenanceManual
