Powersupply
Theservermightcomewithoneofthefollowingpowersupplyconfigurations:
•Onescrew-secured,non-hot-swap300-wattpowersupplyassembly(compliant
with80PLUSGold)
•Onescrew-secured,non-hot-swap250-wattpowersupplyassembly(compliant
with80PLUSBronze)
Note:Ifyouareusinguninterruptiblepowersupplies(UPS),ensurethatyouuse
onlypure-sineUPSwithyourThinkServer
®
server.
Systemfans
Yourservercomeswiththreefanstoprovidepropersystemcoolingandairflow.
InternaldrivesInternaldrivesaredevicesthatyourserverusestoreadandstoredata.Theinternal
drivessupportedbyyourservervarybymodel.
•Internalstoragedrive
–Uptotwo3.5-inchSATAorSASharddiskdrives(HDDs)
–Uptofour2.5-inchSATAorSASHDDsorSATAsolid-statedrives(SSDs)
–OneM.2SATASSD
Note:Theterm“2.5-inchHDDs”hereinafterreferstoallthesupportedtypesof
2.5-inchHDDsandSSDs.
•Opticaldrive
OneslimSATAopticaldrive(availableonsomemodels)
Expansionslots
TheserverhasonePeripheralComponentInterconnectExpress(PCIe)cardsloton
therisercardassembly.
Formoreinformation,see“Rearviewoftheserver”onpage14.
Input/Output(I/O)features
•Frontpanel:
–TwoUSB2.0connectors
•Rearpanel:
–FourUSB3.0connectors
–Serialconnector
–Videographicsarray(VGA)connector
–ThreeRJ-45Ethernetconnectors(oneforsystemmanagement)
Tolocatetheconnectors,refertotherelatedtopicsin“Componentlocations”on
page11
.
Videosubsystem
AnintegratedgraphicscontrollerisavailableinyourservertosupporttheVGA
connectorforconnectingcompatiblevideodevices.Theintegratedgraphics
controllerislocatedintheThinkServerManagementModule(TMM),whichalsois
knownastheBaseboardManagementController(BMC)chiponthesystemboard.
EthernetconnectivityTherearethreeRJ-45Ethernetconnectorsontherearpanelwith10megabits
persecond(Mbps),100Mbps,or1000Mbpsnetworkconnectivity.Formore
information,see“Rearviewoftheserver”onpage14
.
8ThinkServerRS160UserGuideandHardwareMaintenanceManual
