5.InserttheTPMhorizontallyintotheTPMconnectoronthesystemboard.
Figure62.InstallingtheTPM
6.ReinstallthePCIecardifyouhaveremovedit.See“InstallingthePCIecard”onpage56
Tocompletethepartsreplacement,goto“Completingthepartsreplacement”onpage95.Then,youcan
configuretheTPMfunctionintheSetupUtilityprogram.See“ConfiguringtheTPMfunction”onpage33
.
Coin-cellbattery
Yourserverhasaspecialtypeofmemorythatmaintainsthedate,time,andconfigurationinformationfor
built-infeatures.Thecoin-cellbatterykeepstheinformationactivewhenyouturnofftheserver.The
coin-cellbatterynormallyrequiresnochargingormaintenancethroughoutitslife;however,nobatterylasts
forever.Ifthecoin-cellbatteryfails,thedate,time,andconfigurationinformation,includingpasswords,are
lostandanerrormessageisdisplayedwhenyouturnontheserver.
•“Removingthecoin-cellbattery”onpage83
•“Installingthecoin-cellbattery”onpage83
DANGER
Dangerofexplosionifbatteryisimproperlyreplaced.
Whenreplacingthelithiumcoin-cellbattery,useonlythesameoranequivalenttypethatis
recommendedbythemanufacturer.Thebatterycontainslithiumandcanexplodeifnotproperly
used,handled,ordisposedof.
Donot:
•Throworimmerseintowater
•Heattomorethan100°C(212°F)
•Repairordisassemble
