Lenovo ThinkStation P310 - Rear View

Rearview
4
3
5 6 7 8
/
Figure2.Rearview
1Power-cordconnector
2Serialconnector
3VGAconnector
4DisplayPort
®
connectors
5USB3.0connectors(4)6USB2.0connectors(2)
7Microphoneconnector
8PCI/PCI-Expresscardarea(differentcardsprovide
differentconnectors)
9Audioline-inconnector
10Optionalserialconnector
11Cable-lockslots
12Padlockloop
13Audioline-outconnector14Ethernetconnector
15PS/2keyboardandmouseconnectors(somemodels)16Security-lockslot
Note:Adiscretegraphicscard,networkinterfacecard,oraudiocardmightbeinstalledinthePeripheral
ComponentInterconnect(PCI)orPCIExpresscardarea.Ifsuchacardisinstalled,ensurethatyouusethe
connectorsonthecardinsteadofthecorrespondingconnectorsonthecomputer.
1Powercordconnector(availableonsomemodels)
Usedtoconnectthepowercordtoyourcomputerforpowersupply.
210Serialconnector
Usedtoconnectanexternalmodem,aserialprinter,orotherdevicesthatuseaserialconnector.
3VGAconnector
Usedtoconnectavideographicsarray(VGA)monitororotherdevicesthatuseaVGAconnector.
Chapter1.Productoverview3
