Lenze 8400 motec Series User Manual

Parameter reference
Communication-relevant parameters of the operating system
72
Lenze · Decentralised frequency inverter 8400 motec (CANopen option) · EDS84DMOTCAN EN 4.0 - 02/2019
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
12 Parameter reference
This chapter supplements the parameter list and the table of attributes in the software manual and
in the »Engineer« online help for the Inverter Drive 8400 motec by the parameters for CANopen
communication.
12.1 Communication-relevant parameters of the operating system
This chapter lists the communication-relevant parameters of the 8400 motec operating system in
numerically ascending order.
C01501
C01503
 Software manual/»Engineer« online help "Inverter Drives 8400 motec"
Here you will find general information on parameters.
Parameter | Name:
C01501 | Resp. to communication error with MCI
Data type: UNSIGNED_8
Index: 23074
d
= 5A22
h
Configuration of monitoring functions for the Communication Unit
Selection list
0 No Reaction
1Fault
4 WarningLocked
Subcodes Lenze setting Info
C01501/1 1: Fault Resp. to MCI fault 1
• Response to a communication fault.
C01501/2 1: Fault Resp. to MCI fault 2
• Response to an incompatible communication unit.
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01503 | MCI timeout
Data type: UNSIGNED_16
Index: 23072
d
= 5A20
h
Setting range (min. value | unit | max. value)
0 ms 1000
Subcodes Lenze setting Info
C01503/1 200 ms MCI timeout
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
