Lenze 9300 vector - Page 149

Commissioning
Adjusting the motor
Motor selection list
6
6.6
6.6.2

6.6−8
EDSVF9383V EN 6.0−11/2009
Motor dataInformation on the motor
nameplate
C0076C0075C0071C0070C0091C0090C0089C0088C0087C0085C0084C0081C0022C0086Field
T
ni
V
pi
T
nn
V
pn
cos jU
r
[V]
f
r
[Hz]
IN
[A]
n
N
[rpm]
Ls
[mH]
R
s
[W]
P
r
[kW]
Imax
[A]
TypeC86
1089 MDEBAXM−080−12 252 4.16 0.95 20.69 89.00 2510 2.77 87 400 0.68 6 300 1.6 2
1090 MDEBAXM−080−32 213 3.00 0.75 11.69 65.20 1400 2.00 50 400 0.72 6 300 3.5 2
1091 MDEBAXM−080−32 253 5.20 1.30 11.69 65.20 2510 3.46 87 400 0.72 6 300 1.9 3
1092 MDEBAXM−090−12 214 4.05 1.10 6.40 37.00 1420 2.70 50 400 0.77 6 300 2.5 2
1093 MDEBAXM−090−12 254 7.05 2.00 6.40 37.00 2535 4.70 87 400 0.77 6 300 2 2
1094 MDEBAXM−090−32 215 5.40 1.50 4.80 26.00 1415 3.60 50 400 0.77 6 300 2 2
1095 MDEBAXM−090−32 255 9.30 2.70 4.80 26.00 2530 6.20 87 400 0.77 6 300 1 2
1096 MDEBAXM−100−12 216 7.20 2.20 2.90 20.00 1425 4.80 50 400 0.80 6 300 1 1.5
1097 MDEBAXM−100−12 256 12.45 3.90 2.90 20.00 2535 8.30 87 400 0.80 6 300 0.8 1.5
1098 MDEBAXM−100−32 217 9.90 3.00 2.10 17.00 1415 6.60 50 400 0.81 6 300 2.5 1.5
1099 MDEBAXM−100−32 257 17.10 5.35 2.10 17.00 2530 11.40 87 400 0.81 6 300 1.4 1.8
1100 MDEBAXM−112−22 218 12.45 4.00 1.50 11.00 1435 8.30 50 400 0.82 6 300 2 2
1101 MDEBAXM−112−22 258 21.45 7.10 1.50 11.00 2545 14.30 87 400 0.82 6 300 1 2
1102 MDEBAXM−112−32 219 17.85 5.50 2.71 21.40 1425 11.90 50 400 0.84 6 300 1.5 10
1114 MDFMAxx−200−32 224 83.25 30.00 ˘ ˘ 1465 55.50 50 400 0.85 6 300 1 2
1115 MDFMAxx−200−32 264 145.50 52.00 ˘ ˘ 2575 97.00 87 400 0.85 6 300 1 2
