Lenze 9300 vector - Page 291

Configuration
Code table
8
8.5

8.5−2
EDSVF9383V EN 4.0−03/2006
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0005

Signal CFG
Selection of the basic
configuration
1000
0 Common Modified basic
configuration
The first two digits indicate the
predefined basic function, e. g.:
l 01xxx: Speed control
The third digit indicates
additional functions:
l xx0xx: No additional
function
l xx1xx: Brake control
l xx2xx: Setpoint selection via
motor potentiometer
l xx3xx: PID controller
l xx4xx: Mains failure control
l xx5xx: Setpoint selection via
master frequency
l xx6xx: Gearbox factor −
analog trimming
l xx7xx: Gearbox factor −
digital trimming
l xx8xx: Master frequency
ramp function generator
The fourth digit indicates the
predefined voltage source for
the control terminals:
l xxx0x: External supply
voltage
l xxx1x: Internal supply
voltage
The fifth digit indicates the
predefined device control
l xxxx0: Terminal control
l xxxx1: RS232, RS485 or
optical fibre
l xxxx3: INTERBUS or
PROFIBUS−DP
l xxxx5: System bus (CAN)
100 CFG: emty All internal
connections are
removed
1000 Speed mode Speed control
2000 Step mode Step control
3000 Lead screw Traversing control
4000 Torque mode Torque control
5000 DF master Digital frequency
master
6000 DF slv bus Master frequency
slave (bar)
7000 DF slv cas Digital frequency
slave (cascade)
8000 Dancer ctrl e Dancer position
control with
external diameter
measurement
9000 Dancer ctrl i Dancer position
control with
internal diameter
measurement
C0006

Op mode 5
Selection of the operating mode
for the motor control
1 vector ctrl Vector control
without or with
speed feedback
In case of the first selection
enter the motor data and
identify them with C0148.
 6.8−8
5 V / f V/f characteristic
control
Commissioning without
identification of the motor data
is possible
l Advantage of identification
with C0148: Improved
smooth running at low
speeds
 6.8−4
C0009 LECOM
address
1 1 {1} 99 LECOM controller address
l Bus device number when
operated via interface
l 10, 20 ... 90 reserved for
broadcast to device groups
with RS232, RS485, optical
fibre
