Technical data
General data and operating conditions
3
100
EDK82EV222 DE/EN/FR 13.0
3 Technical data
General data and operating conditions
Conformity and approval
CE 2006/95/EC
Low−Voltage Directive
2004/108/EG EMC Directive
EAC
TP TC 020/2011
(TR CU 020/2011)
Electromagnetic
compatibility of technical
means
Eurasian Conformity
TR CU: Technical Regulation of
Customs Union
TP TC 004/2011
(TR CU 004/2011)
On safety of low voltage
equipment
Eurasian Conformity
TR CU: Technical Regulation of
Customs Union
UL cULus Power Conversion Equipment (File No. E132659)
Protection of persons and equipment
Type of protection EN 60529
IP20
IP41 in case of thermally separated installation (push−through
technique) between the control cabinet (inside) and the
environment.
NEMA 250 Protection against accidental contact in accordance with type 1
Earth leakage current IEC/EN 61800−5−1 > 3.5 mA AC
> 10 mA DC
Observe regulations and safety
instructions!
Insulation of control
circuits
IEC/EN 61800−5−1 Safe mains isolation through double (reinforced) insulation
Insulation resistance IEC/EN 61800−5−1
< 2000 m site altitude: overvoltage category III
> 2000 m site altitude: overvoltage category II
Protective measures Against short circuit, earth fault (protected against short to earth on power−up, limited
protection against short to earth during operation), overvoltage, motor stalling, motor
overtemperature (input for PTC thermistor or thermal contact, I
2
t monitoring)
EMC
Noise emission
IEC/EN 61800−3
Cable−guided, category C1 or C2 when using shielded motor
cables
1)
, dependent on the device variant with integrated
interference suppression or additional RFI/mains filter
0.25 ... 11 kW
E82xVxxxKxC0xx no additional measures
E82xVxxxKxC2xx with external filter techniques
15 ... 90 kW
E82EVxxxK4B3xx no additional measures
E82xVxxxK4B2xx with external filter techniques
Interference immunity IEC/EN 61800−3 Category C3
1)
Motor cable lengths depend on the inverter type and the switching frequency
