Mechanical installation
Mounting in cold−plate design
4
110
EDK82EV222 DE/EN/FR 13.0
Mounting in cold−plate design
For this mounting variant you require the controller type E82CV...
The following points are important for safe and reliable operation of the controller:
ƒ Good thermal connection to the cooler
– The contact surface between the collective cooler and the controller must be at least as
large as the cooling plate of the controller.
– Plane contact surface, max. deviation 0.05 mm.
– When attaching the collective cooler to the controller, make sure to use all specified screw
connections.
ƒ Observe the thermal resistance R
th
given in the table. The values are valid for controller
operation under rated conditions.
Power to be dissipated by the heatsink Cooling path of heatsink − ambience
8200 vector
P
loss
[W] R
th
[K/W]
E82CV251K2C
20
£ 1.50
E82CV371K2C
27
£ 1.50
E82CV551K2C
33
£ 1.00
E82CV751K2C
40
£ 1.00
E82CV152K2C
67
£ 0.30
E82CV222K2C
1)
87
£ 0.30
E82CV551K4C
33
£ 1.00
E82CV751K4C
40
£ 1.00
E82CV152K4C
67
£ 0.30
E82CV222K4C
87
£ 0.30
1)
Max. output current at switching frequency of 8 kHz: 8.5 A!
Ambient conditions
ƒ The rated data and the derating factors at increased temperature also apply to the ambient
temperature of the drive controllers.
ƒ Temperature at the cooling plate of the drive controller: max. 75 °C.
