Commissioning
Parameter setting with the XT EMZ9371BC keypad
Vector control
7
141
EDK82EV222 DE/EN/FR 13.0
CommentSwitch−on sequence
8. Set the minimum output frequency (C0010)
Lenze setting: 0.00 Hz
9. Set the maximum output frequency (C0011)
Lenze setting: 50.00 Hz
10. Set the acceleration time T
ir
(C0012)
Lenze setting: 5.00 s
11. Set the deceleration time T
if
(C0013)
Lenze setting: 5.00 s
12. Set the V/f−rated frequency (C0015)
Lenze setting: 50.00 Hz
13. Set the V
min
boost (C0016)
Lenze setting: depends on the controller type
The Lenze setting is suitable for all common
applications
14. Activate the motor temperature monitoring (C0119) if you
have connected a PTC or thermal contact to terminal X2.2
Lenze setting: switched off
Possible settings( 152)
When all settings are complete:
15. Select setpoint E.g. via potentiometer at terminals 7, 8, 9
16. Enable the controller Terminal X3/28 = HIGH
17. The drive is now running. If the drive does not start, additionally press
Vector control
The following instructions apply to controllers equipped with a standard−I/O function module and
a three−phase AC motor which has been selected according to a power−based assignment.
Switch−on sequence Comment
1. Plug in the keypad
2. Ensure that controller inhibit is active after mains
connection
Terminal X3/28 = LOW
3. Switch on the mains
4. After approx. 3 s the keypad is in the operating level and
displays the output frequency (C0050) and the device
utilisation (C0056)
5. For quick commissioning you select the "Quick start"
menu
The submenu "VectorCtrl qu" contains the codes
which you require for commissioning a standard
application. The digital inputs are configured in
Lenze setting:
X3/E1, X3/E2: activation of fixed setpoints (JOG)
X3/E3: activation of DC injection brake (DCB)
X3/E4: CW rotation/CCW rotation
A Change the menu level with
B Change to the "Quick start" menu and there to the
"VectorCtrl qu" submenu with 
C Change to the code level with to parameterise your
drive
