Electrical installation
Mains connection
Fuses and cable cross−sections according to UL
5
124
EDK82EV222 DE/EN/FR 13.0
Fuses and cable cross−sections according to UL
Supply conditions
Range Description
Fuses l Only in accordance with UL 248
l System short−circuit current up to 5000 A
rms
: All classes are permissible
l System short−circuit current up to 50000 A
rms
: Only classes "CC", "J", "T" or "R" permissible
Circuit−breaker l Only in accordance with UL 489
l Manufacturer/type
– ABB: S 200 U Charact. K
– Schneider Electric: Multi9 C60 Charact. C
– Moeller: FAZ−C Charact. C
Warnings!
Circuit breakers for 400/500 V devices only for use in WYE 480/277V source.
Cables l Only in accordance with UL
l The cable cross−sections specified in the following apply under the following conditions:
– Conductor temperature < 60 °C
– Ambient temperature < 40 °C
Observe all national and regional regulations!
Operation with increased rated power
Operation at an increased rated power is not UL−certified.
Operation at rated power
8200 vector
Rated fuse current / cable cross−section
Fuse Circuit−breaker
Type L1, L2, L3, N, PE Type L1, L2, L3, N, PE
Type [A] [AWG] [A] [AWG]
Mains 1/N/PE AC 230/240 V − operation without mains choke/mains filter
E82xV251K2C
10 16 15
14
4)
E82xV371K2C 10 16 15
14
4)
E82xV551K2C 10 16 15
14
4)
E82xV751K2C 15 14 15
14
4)
E82xV152K2C 20 2 x 16 25
2 x 14
4)
E82xV222K2C 20 2 x 16 30
2 x 14
4)
