Electrical installation
Mains connection
Fuses and cable cross−sections according to EN 60204−1
5

123
EDK82EV222 DE/EN/FR 13.0
ELCB
1)
Cable cross−sectionRated fuse current8200 vector ELCB
1)
Laying system L1, L2, L3, N, PECircuit−breakerFuse
8200 vector
ELCB
1)
CB2
Circuit−breakerFuse
8200 vector
[mA][mm
2
][mm
2
][A][A]Type
E82xV251K2C 10 C10 1.5 −
³ 30
E82xV371K2C 10 C10 1.5 −
E82xV551K2C 10 B10 1.5 −
E82xV751K2C 10 B10 1.5 −
E82xV152K2C 16 B16 2 x 1.5 −
E82xV222K2C 16 B16 2 x 1.5 −
Mains 3/PE AC 230/240 V − operation without mains choke/mains filter
E82xV551K2C 6 B6 1 −
³ 30
E82xV751K2C 6 B6 1 −
E82xV152K2C 16 B16 2 x 1.5 −
E82xV222K2C 20 B20 − 2 x 1.5
Mains 3/PE AC 230/240 V − operation with mains choke/mains filter
E82xV551K2C 6 B6 1 −
³ 30
E82xV751K2C 6 B6 1 −
E82xV152K2C 10 B10 1.5 −
E82xV222K2C 16 B16 2 x 1.5 −
Mains 3/PE AC 400/500 V − operation without mains choke/mains filter
E82xV551K4C
6
B6
1 −
³ 300
2)
³ 30
3)
E82xV751K4C
6
B6
1 −
E82xV152K4C
10
B10
1.5 −
E82xV222K4C
10
B10
1.5 −
Mains 3/PE AC 400/500 V − operation with mains choke/mains filter
E82xV551K4C
6
B6
1 −
³ 300
2)
³ 30
3)
E82xV751K4C
6
B6
1 −
E82xV152K4C
10
B10
1.5 −
E82xV222K4C
10
B10
1.5 −
1)
Earth−leakage circuit breaker
2)
Is used with E82EVxxxKxC0xx (with integrated EMC filter)
3)
Is used with E82EVxxxKxC2xx (without integrated EMC filter)
4)
Pin−end connector required
