Mechanical installation
Mounting with thermal separation (push−through technique)
4
106
EDK82EV222 DE/EN/FR 13.0
Mounting with thermal separation (push−through technique)
For this mounting variant you require the controller type E82DV...
8200 vector 0.25 ... 0.75 kW
8200vec027
1 Frame
2 Screw M4x10
3 Seal
4 Hexagon nut M4
5 Rear panel of the control cabinet
Dimensions [mm]
8200 vector a b b
2
c
1
c
2
d
1
d
2
d
3
e
1)
f
1)
g
E82DV251K2C
79.4
124 120
4.2 71 5
52
10 140 100 4.5
E82DV371K2C
E82DV551KxC
184 180 82
E82DV751KxC
1)
If the function module is attached: observe mounting clearance and cable bending radius. The terminals of
function modules in PT design protrude above the housing by 14 mm.
