Electrical installation
Mains connection
Fuses and cable cross−sections according to EN 60204−1
5
122
EDK82EV222 DE/EN/FR 13.0
Fuses and cable cross−sections according to EN 60204−1
Supply conditions
Range Description
Fuses l Utilisation category: only gG/gL or gRL
Cables Laying systems B2 and C: Use of PVC−insulated copper cables, conductor temperature < 70 °C,
ambient temperature < 40 °C, no bundling of the cables or cores, three loaded cores. The data are
recommendations. Other dimensionings/laying systems are possible (e.g. in accordance with
VDE 0298−4).
RCCB l Controllers can cause a DC current in the PE conductor. If a residual current device (RCD) or a fault
current monitoring unit (RCM) is used for protection in the case of direct or indirect contact, only
one RCD/RCM of the following type can be used on the current supply side:
– Type B (universal−current sensitive) for connection to a three−phase system
– Type A (pulse−current sensitive) or type B (universal−current sensitive) for connection to a
1−phase system
Alternatively another protective measure can be used, like for instance isolation from the
environment by means of double or reinforced insulation, or isolation from the supply system by
using a transformer.
l Earth−leakage circuit breakers must only be installed between mains supply and controller.
Observe all national and regional regulations!
Operation with increased rated power
System Manual
Operation at rated power
8200 vector
Rated fuse current Cable cross−section
ELCB
1)
Fuse Circuit−breaker Laying system L1, L2, L3, N, PE
B2 C
Type [A] [A] [mm
2
] [mm
2
] [mA]
Mains 1/N/PE AC 230/240 V − operation without mains choke/mains filter
E82xV251K2C
10 C10 1.5 −
³ 30
E82xV371K2C 10 C10 1.5 −
E82xV551K2C 10 B10 1.5 −
E82xV751K2C 16 B16 2.5
4
) −
E82xV152K2C 20 B20 2 x 1.5 −
E82xV222K2C Operation only permitted with mains choke or mains filter
Mains 1/N/PE AC 230/240 V − operation with mains choke/mains filter
