Commissioning
Important codes for quick commissioning
7

152
EDK82EV222 DE/EN/FR 13.0
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0034
*

(A)
uSEr
Range of
setpoint
selection
Application I/O
Observe jumper position of the
function module!
1
X3/1U, X3/1I 0 0 Unipolar voltage 0 ... 5 V / 0 ... 10 V
2
X3/2U, X3/2I 1 Bipolar voltage −10 V ... +10 V Minimum output frequency (C0010)
not effective
2 Current 0 ... 20 mA
3 Current 4 ... 20 mA Reversal of rotation direction only
possible with a digital signal.
4 Current 4 ... 20 mA open−circuit monitored Reversal of rotation direction only
possible with a digital signal.
TRIP Sd5 at I < 4 mA
C0037 JOG1 20.00 −650.00 {0.02 Hz}
650.00
JOG = fixed setpoint
Additional fixed setpoints ðC0440
C0038 JOG2 30.00 −650.00 {0.02 Hz}
650.00
C0039 JOG3 40.00 −650.00 {0.02 Hz}
650.00
C0050
*
uSEr
Output
frequency
(MCTRL1−NOUT)
−650.00 {Hz}
650.00
Read only: Output frequency without
slip compensation
C0087 Rated motor
speed
à
300 {1 rpm}
16000 à Device−dependent
C0088 Rated motor
current
à
0.0 0.1 (A)
650.0 à Device−dependent
0.0 ... 2.0 x rated output current of
the controller
C0089 Rated motor
frequency
50 10 {1 Hz}
960
C0090 Rated motor
voltage
à
50 {1 V}
500 à 230 V for 230 V controllers,
400 V for 400 V controllers
C0091 Motor cos 
à
0.40 {0.1}
1.0 à Device−dependent
C0119

Configuration
of motor
temperature
monitoring (PTC
input) / earth
fault detection
0 0 PTC input inactive Earth fault
detection active
l Configure signal output in C0415
l If several parameter sets are
used, monitoring has to be set
separately for every parameter
set.
l Deactivate earth fault detection
if the earth fault detection is
actuated unintentionally.
l If the earth fault detection is
activated, the motor starts with a
delay of approx. 40 ms after
controller enable has been set.
1 PTC input active,
TRIP effected
2 PTC input active,
warning effected
3 PTC input inactive Earth fault
detection inactive
4 PTC input active,
TRIP effected
5 PTC input active,
warning effected
