Commissioning
Important codes for quick commissioning
7
153
EDK82EV222 DE/EN/FR 13.0
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0140
*
Additive
frequency
setpoint
(NSET1−NADD)
0.00 −650.00 {0.02 Hz}
650.00
l Selection via " function of the
keypad or parameter channel
l Acts additively on the main
setpoint
l Value will be stored when
switching the mains or removing
the keypad
l C0140 is only transferred during
parameter set transfer with GDC
(not with keypad)
C0148
*
!
Identifying
motor data
0 0 Ready Only when the motor is cold!
1. Inhibit controller, wait until drive
is at standstill
2. Enter the correct values from the
motor nameplate in C0087,
C0088, C0089, C0090, C0091
3. Set C0148 = 1, confirm with
4. Enable controller:
The identification
– starts, goes out
– the motor "whistles" faintly
but it does not rotate!
– takes approx. 30 s
– is completed when is lit
again
5. Inhibit controller
1 Start identification
l V/f rated frequency (C0015), slip
compensation (C0021) and motor
stator inductance (C0092) are
calculated and saved
l The motor stator resistance (C0084) =
total resistance of the motor cable
and motor is measured and saved
C0517
*
User menu l After mains switching or in the
# function the code from
C0517/1 is displayed.
l In the Lenze setting the user
menu contains the most
important codes for
commissioning the operating
mode "V/f characteristic control
with a linear characteristic"
l If the password protection is
active, only the codes entered in
C0517 can be freely accessed
l If less than 10 codes are required,
assign the value "0" (zero) to the
memory locations not used.
Please observe that the software
automatically assigns code
C0050 to a memory location that
is not used, if it has not been
explicitly assigned to another
memory location.
1
Memory 1 50 C0050 Output frequency (MCTRL1−NOUT)
2
Memory 2 34 C0034 Range of analog setpoint selection
3
Memory 3 7 C0007 Fixed configuration of digital input
signals
4
Memory 4 10 C0010 Minimum output frequency
5
Memory 5 11 C0011 Maximum output frequency
6
Memory 6 12 C0012 Acceleration time main setpoint
7
Memory 7 13 C0013 Deceleration time main setpoint
8
Memory 8 15 C0015 V/f rated frequency
9
Memory 9 16 C0016 V
min
boost
10
Memory 10 2 C0002 Parameter set transfer
Possible entries for C0517
xxxx All codes apart from the codes labelled
with "(A)".
Syntax:
Codes: C0517/x = cccc
Subcodes: C0517/x = cccc.ss
