Technical data
General data and operating conditions
3
102
EDK82EV222 DE/EN/FR 13.0
Ambient conditions
DC mains connection
Max. mains voltage range
450 V − 0 % ... 740 V + 0 %
E82xV251K2... and E82xV371K2... not possible
E82xV551K2... to E82xV752K2... 140 V − 0 % ... 370 V + 0 %
E82xV551K4... to E82xV903K4...
450 V − 0 % ... 775 V + 0 % Operation at rated power
450 V − 0 % ... 625 V + 0 % Operation at an increased rated
power
Operating conditions The DC voltage must be symmetrical to PE.
The controller will be destroyed if the +U
G
conductor or −U
G
conductor is earthed.
Motor connection
Length of the motor cable
< 50 m shielded
< 100 m unshielded
For rated mains voltage and switching frequency £ 8 kHz
without additional output filters.
For compliance with EMC regulations, the permissible cable
length may be different.
Mechanical
Vibration resistance
(9.81 m/s
2
= 1 g)
Germanischer Lloyd
5 ... 13.2 Hz
Amplitude ±1 mm 13.2 ... 100 Hz:
acceleration resistant up to 0.7 g
IEC/EN 60068−2−6
10 ... 57 Hz
Amplitude 0.075 mm 57 ... 150 Hz:
acceleration resistant up to 1 g
Mounting conditions
Mounting place
In the control cabinet
Mounting position Vertical
Dimensions,
free spaces
Chapter "Mechanical installation"
Weights Chapter "Technical data", "Operation at rated power" or
"Operation at increased rated power"
