Electrical installation
Wiring
Mains choke/mains filter assignment
5

116
EDK82EV222 DE/EN/FR 13.0
Operation at rated power on 400/500 V mains, 3/PE
8200 vector Mains choke
Interference voltage category (EN 61800−3) and motor cable
length
Component Component
Type Var. Type C2 Max.
[m]
C1 Max.
[m]
E82xV551K4C
0xx
EZAELN3002B153
− 20 −
1)
2xx
E82ZZ75134B200 20 E82ZZ75134B200 20
E82ZZ75134B210 50 E82ZZ75134B210 50
E82xV751K4C
0xx
EZAELN3004B742
− 20 −
1)
2xx
E82ZZ75134B200 20 E82ZZ75134B200 20
E82ZZ75134B210 50 E82ZZ75134B210 50
E82xV152K4C
0xx
EZAELN3004B742
− 20 −
1)
2xx
E82ZZ22234B200 20 E82ZZ22234B200 20
E82ZZ22234B210 50 E82ZZ22234B210 50
E82xV222K4C
0xx
EZAELN3006B492
− 20 −
1)
2xx
E82ZZ22234B200 20 E82ZZ22234B200 20
E82ZZ22234B210 50 E82ZZ22234B210 50
1)
The motor cable length depends on the inverter type and the switching frequency
