Lenze E82EV User Manual

Commissioning
Important codes for quick commissioning
7

150
EDK82EV222 DE/EN/FR 13.0
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0007

uSEr
(Continu
ation)
E4 E3 E2 E1
41
JOG1/3 DCB TRIP−Set DFIN1−ON
42
QSP DCB TRIP−Set DFIN1−ON
43
CW/CCW QSP TRIP−Set DFIN1−ON
44
UP DOWN PAR DFIN1−ON
45
CW/CCW QSP PAR DFIN1−ON
46
H/Re PAR QSP JOG1/3
47
CW/QSP CCW/QSP H/Re JOG1/3
48
PCTRL1−OF
F
DCB PCTRL1−I−
OFF
DFIN1−ON
49
PCTRL1−OF
F
JOG1/3 QSP DFIN1−ON
50
PCTRL1−OF
F
JOG1/3 PCTRL1−I−
OFF
DFIN1−ON
51
DCB PAR PCTRL1−I−
OFF
DFIN1−ON
255 Free configuration in C0410 Read only
Do not change C0007 since settings
in C0410 may get lost
C0010
uSEr
Minimum
output
frequency
0.00 0.00
à 14.5 Hz
{0.02 Hz}
650.00
l C0010 not effective in the case of
bipolar setpoint selection (−10 V
... + 10 V)
l C0010 only limits the analog
input 1
l In the case of a max. output
frequency > 50 Hz the switching
threshold of the auto DCB in
C0019 has to be increased.
l From software 3.5: If
C0010 > C0011, the drive does
not start when controller enable
is set.
à Speed setting range 1 : 6 for
Lenze geared motors: For
operation with Lenze geared
motors has to be set
necessarily.
C0011
uSEr
Maximum
output
frequency
50.00 7.50
à 87 Hz
{0.02 Hz}
650.00
C0012
uSEr
Acceleration
time main
setpoint
5.00 0.00 {0.02 s}
1300.00
Reference: frequency change 0 Hz ...
C0011
l Additional setpoint ðC0220
l Acceleration times that can be
activated via digital signals ð
C0101
