Troubleshooting and fault elimination
Fault elimination
Fault messages
8

159
EDK82EV222 DE/EN/FR 13.0
RemedyCauseFaultPC
1)
Keypad
ce6
$
67 System bus (CAN)
function module on
FIF has the
"Warning" or
"BUS−OFF" status
(configurable in
C0126)
CAN controller reports "Warning"
or "BUS−OFF" status
l Check bus termination
l Check shield connection of the
cables
l Check PE connection
l Check bus load, reduce the baud
rate, if necessary
ce7
$
68 Communication
error during remote
parameterisation
via system bus
(C0370)
(configurable in
C0126)
Node does not respond or is not
available
l Check bus termination
l Check shield connection of the
cables
l Check PE connection
l Check bus load, reduce the baud
rate, if necessary
For operation with application
I/O:
Parameter set change−over has
been parameterised incorrectly
The "parameter set change−over"
signal (C0410/13, C0410/14) must be
connected to the same source in all
paramerter sets
EEr
$
91 External fault
(TRIP−SET)
A digital signal assigned to the
TRIP−Set function is activated
Check external encoder
ErP0
...
ErP19
$
− Communication
abort between
keypad and
standard device
Various Contact Lenze
FAn1
$
95
Fan failure
(only 8200 motec
3 ... 7.5 kW)
TRIP or warning
configurable in
C0608
Fan is defective Replace fan
FAn1
− Fan is not connected Connect fan
Check wiring
H05
$
105 Internal fault Contact Lenze
id1
$
140 Faulty parameter
identification
Motor is not connected Connect motor
LP1
$
32 Motor phase error
(display when
C0597 = 1)
l Failure of one/several motor
phases
l Motor current is too low
l Check motor supply cables
l Check V
min
boost,
l Connect motor with a
corresponding power or adapt
motor with C0599
LP1
182 Motor phase error
(Display when
C0597 = 2)
