Lenze E82EV User Manual

Inbetriebnahme
Wichtige Codes für die schnelle Inbetriebnahme
7

69
EDK82EV222 DE/EN/FR 13.0
WICHTIGEinstellmöglichkeitenCode
AuswahlLenzeBezeichnungNr.
C0007

uSEr
(Forts.)
E4 E3 E2 E1
l UP/DOWN = Motorpoti−Funktio-
nen
l H/Re = Hand/Remote−Umschal-
tung
l PCTRL1−I−OFF = I−Anteil Prozess-
regler ausschalten
l DFIN1−ON = Digitaler Frequen-
zeingang 0 ... 10 kHz
l PCTRL1−OFF = Prozessregler aus-
schalten
20
CCW/QSP CW/QSP TRIP−Set JOG1/3
21
CCW/QSP CW/QSP UP DOWN
22
CCW/QSP CW/QSP UP JOG1/3
23
H/Re CW/CCW UP DOWN
24
H/Re PAR UP DOWN
25
H/Re DCB UP DOWN
26
H/Re JOG1/3 UP DOWN
27
H/Re TRIP−Set UP DOWN
28
JOG2/3 JOG1/3
PCTRL1−I−
OFF
DFIN1−ON
29
JOG2/3 DCB
PCTRL1−I−
OFF
DFIN1−ON
30
JOG2/3 QSP
PCTRL1−I−
OFF
DFIN1−ON
C0007

uSEr
(Forts.)
E4 E3 E2 E1
31
DCB QSP
PCTRL1−I−
OFF
DFIN1−ON
32
TRIP−Set QSP
PCTRL1−I−
OFF
DFIN1−ON
33
QSP PAR
PCTRL1−I−
OFF
DFIN1−ON
34
CW/QSP CCW/QSP
PCTRL1−I−
OFF
DFIN1−ON
35
JOG2/3 JOG1/3 PAR DFIN1−ON
36
DCB QSP PAR DFIN1−ON
37
JOG1/3 QSP PAR DFIN1−ON
38
JOG1/3 PAR TRIP−Set DFIN1−ON
39
JOG2/3 JOG1/3 TRIP−Set DFIN1−ON
40
JOG1/3 QSP TRIP−Set DFIN1−ON
