Commissioning
Commissioning steps
6
l
28
EDS82ZAFPC201 EN 4.0
Step Description Detailed
information
9.
Use C1511 to assign the process data output words (POW) of the master to
the process data input words of the standard device.
Lenze setting:
POW1: DRIVECOM control word (DRIVECOM−CTRL)
POW2:
Setpoint1 (NSET1−N1)
POW3:
Setpoint2 (NSET1−N2)
POW4:
Additional setpoint (PCTRL1−NADD)
POW5:
Actual process controller value (PCTRL1−ACT)
POW6:
Process controller setpoint (PCTRL1−SET1)
POW7:
Reserved (FIF−RESERVED)
POW8:
Torque setpoint or torque limit value (MCTRL1−MSET)
POW9:
PWM voltage (MCTRL1−VOLT−ADD)
POW10:
PWM angle (MCTRL1−PHI−ADD)
10.
Use C1510 to assign the process data output words of the standard device to
the process data input words (PIW) of the master.
Lenze setting:
PIW1: DRIVECOM status word (DRIVECOM STAT)
PIW2:
Output frequency with slip (MCTRL1−NOUT+SLIP)
PIW3:
Output frequency without slip (MCTRL1−NOUT)
PIW4:
Apparent motor current (MCTRL1−IMOT)
PIW5:
Actual process controller value (PCTRL1−ACT)
PIW6:
Process controller setpoint (PCTRL1−SET1)
PIW7:
Process controller output (PCTRL1−OUT)
PIW8:
Controller load (MCTRL1−MOUT)
PIW9:
DC−bus voltage (MCTRL1−DCVOLT)
PIW10:
Ramp function generator input (NSET1−RFG1−IN)
11.
Enable process output data with C1512 = 65535.
l Only required if C1511 has been changed.
l Do not deactivate the process data words used by setting the respective
subcodes of code C1511 = 0.
l The value in C1512 is volatile and all process data are enabled after every
switch−on.
12. Enable the standard device via terminal 28 (CINH).
l Set terminal 28 to HIGH level.
13. Select the setpoint.
l The master transmits the setpoint via the selected process data output
word.
14. Change to the READY TO SWITCH ON state:
l The master transmits the DRIVECOM control word:
0000 0000 0111 1110
bin
(007E
hex
).
15. The standard device in the READY TO SWITCH ON state.
l The master receives the DRIVECOM status word:
xxxx xxxx x01x 0001
bin.
16. Change to the OPERATION ENABLED state.
l The master transmits the DRIVECOM control word:
0000 0000 0111 1111
bin
(007F
hex
).
17. The drive starts up.
