7.2.6 Transfering parameters to other controllers
Parameter s ettings can be easily copied from one basic device to another by
using the keypad.
For this purpose use the menu ”Load/Store”:
Danger!
During the parameter transfer from the keypad to the basic
device the control terminals can adopt undefined states!
Therefore the plugs X5 and X6 must be disconnected from the
basic device before the transfer takes place. This ensures that the
controller is inhibited and all control terminals have the defined
state ”LOW”.
Note!
After copying the parameter sets into the keypad XT
(C0003 = 11) always the parameter set last-loaded via C0002 is
activated.
Thus the current parameters still remain active after copying.
ƒ Before copying, save the current parameters in the parameter
set and load this parameter set into the controller via C0002.
Step Key
sequence
Action
1. Connect the keypad to the
basic device 1
2. Inhibit c ontroller: TerminalX5/28=LOW
The drive coasts.
3. Select C0003 in the menu
”Load/Store” C0003
Select the code C0003 ”PAR SAVE” in the
menu ”Load/Store” using the arrow keys.
4. Change to the parameter level Display ”0” and ”READY”
5. Copy all parameter set into the
keypad
The settings stored in the keypad are
overwritten.
Set ”11” ”Save extern”
6. Start copying The status display ”RDY” goes off. ”BUSY”
is shown as parameter value.
If ”BUSY” goes OFF after approx. one
minute, all parameter sets have been
copied into the keypad.The status display
”RDY” is lit.
7.
Change to the code level
A Display of the operating level
B Display C0003 and ”PAR SAVE”
8. Enable controller Terminal X5/28 = HIGH
9. Remove keypad from the basic
device 1
Copying parameter sets from
the basic device into the
keypad
