Lenze EVF9327

Configuration
Code table
8
8.3

8.3-39
EDSVF9333V EN 3.0-06/2005
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0655 Numerator 1 -32767 {1} 32767 Configuration of conversion
factor with numerator and
denominator, function block
CONV5
See System
Manual
(extension)
C0656 Denominator 1 1 {1} 32767
OUT [rpm] = IN [%] ⋅
15000 rpm
100 %
⋅
C0655
C0656
C0657

CFG: IN 1000 FIXED0%  Selection list 1 Configuration of analog input
signal, function block CONV5
C0658 DIS: IN -199.99 {0.01 %} 199.99 Function block CONV5
z Display of the signal linked in
C0657
C0661

CFG: IN 1000 FIXED0%  Selection list 1 Configuration of analog input
signal, function block ABS1
z Converts bipolar signals into
unipolar signals
See System
Manual
(extension)
C0662 DIS: IN -199.99 {0.01 %} 199.99 Function block ABS1
z Display of the signal linked in
C0661
C0671 RFG1 Tir 0.00 0.00 {0.01 s} 999.90
Acceleration time T
ir
and
deceleration time T
if
, function
block RFG1
z Acceleration and deceleration
ramp
See System
Manual
(extension)
C0672 RFG1 Tif 0.00 0.00 {0.01 s} 999.90
C0673

CFG: IN 1000 FIXED0%  Selection list 1 Configuration of analog input
signal, function block RFG1
z Selection of a final value at
RFG1-OUT
C0674

CFG: SET 1000 FIXED0%  Selection list 1 Configuration of analog input
signal, function block RFG1
z Selection of a starting value at
RFG1-OUT
C0675

CFG: LOAD 1000 FIXED0  Selection list 2 Configuration of digital input
signal, function block RFG1
z HIGH: RFG1-OUT is set to the
value at RFG1-Set
z LOW: The signal at RFG1-OUT
travels along the ramps
towards the input value at
RFG1-IN
C0676 -199.99 {0.01 %} 199.99 Function block RFG1
z Display of the signals linked in
C0673 and C0674
1 DIS: RFG1 RFG1-IN
2 DIS: RFG1 RFG1-SET
C0677 DIS: LOAD 0 1 Function block RFG1
z Display of the signal linked in
C0675
