Lenze EVF9327

Configuration
Code table
8
8.3

8.3-57
EDSVF9333V EN 3.0-06/2005
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0870

 Selection list 2 Configuration of digital input
signals, function block DCTRL
See System
Manual
(extension)
1 CFG: CINH 1000 FIXED0 DCTRL-CINH1
HIGH = Controller inhibit
2 CFG: CINH 1000 FIXED0 DCTRL-CINH2
HIGH = Controller inhibit
C0871

CFG: TRIP-SET 54 DIGIN4  Selection list 2 Configuration of digital input
signal, function block DCTRL
z HIGH = fault message EEr
C0876

CFG: TRIP-RES 55 DIGIN5  Selection list 2 Configuration of digital input
signal, function block DCTRL
z LOW-HIGH edge = TRIP reset
C0878
Function block DCTRL
z Display of the signals linked in
C0870, C0871 and C0876
See System
Manual
(extension)
1 DIS: CINH1
2 DIS: CINH2
3 DIS: TRIP-SET
4 DIS: TRIP-RES
C0879
Resetting control words
z C0879=1performsonereset
1 Reset C135 0 0 Ready
2 Reset AIF 0
1 Reset
3 Reset CAN 0
C0880

 Selection list 2
Configuration of digital input
signals, function block DCTRL
z Select parameter set
z Selection of a parameter set
via binary coding of t he digital
input signals
See System
Manual
(extension)
1 CFG: PAR*1 1000 FIXED0 C0880/
1
C0880/
2
Selected
parameter set
2 CFG: PAR*2 1000 FIXED0
0 0 Parameter set 1
0 1 Parameter set 2
1 0 Parameter set 3
1 1 Parameter set 4
C0881

CFG: PAR-LOAD 1000 FIXED0  Selection list 2 Configuration of digital input
signal, function block DCTRL
z LOW-HIGH edge = Load
selected parameter set into
C0880
See System
Manual
(extension)
C0884
Function block DCTRL
z Display of the signals linked in
C0880 and C0881
See System
Manual
(extension)
1 DIS: PAR*1
2 DIS: PAR*2
3 DIS: PAR-LOAD
C0885

CFG: R 51 DIGIN1  Selection list 2
Configuration of digital input
signals, function block R/L/Q
z Truth table:
Inputs Outputs
RLR/LQSP
000/11
1000
0110
11––
– State is unchanged
See System
Manual
(extension)
C0886

CFG: L 52 DIGIN2  Selection list 2
C0889 0 1
Function block R/L/Q
z Display of the signals linked in
C0885 and C0886
1 DIS: R
2 DIS: L
C0890

CFG: N-SET 5050 NSET-NOUT  Selection list 1 Configuration of analog input
signal, function block MCTRL
z Speed setpoint
 8.2-25
 8.2-48
