Lenze EVF9327

Configuration
Code table
8
8.3

8.3-56
EDSVF9333V EN 3.0-06/2005
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0864 Output of the signal type,
function block CAN-OUT
See System
Manual
(extension)
1 TYPEOUT1.W2 0 0 analog Analog signal CAN-OUTx.Wx (C0860) is output
to X4
2 TYPEOUT2.W1 0 1 digital 0-15 Digital signal
bit 0 ... bit 15
FDO-00 ... FDO-15 (LOW word,
C0116/1 ... C0116/15) are output
to X4
3 TypeOUT3.W1 0 2 low phase Low phase CAN-OUTx.D1 (LOW word,
C0861) is output to X4
C0865 Output of the signal type,
function block CAN-OUT
1 TYPEOUT1.W3 0 0 analog Analog signal CAN-OUTx.Wx (C0860) is output
to X4
2 TYPEOUT2.W2 0 1 digital 16-31 Digital signal
bit 16 ... bit 31
FDO-16 ... FDO-31 (HIGH word,
C0116/16 ... C0116/31) are
output to X1
3 TYPEOUT3.W2 0 2 high phase High phase CAN-OUTx.D1 (HIGH word,
C0861) is output to X4
C0866 -32768.00 {0.01 %} 32767.00 Process input words, function
block CAN-IN
z Read only
z 100% = 16384
See System
Manual
(extension)
1 DIS: IN1.W1
CAN-IN1
2 DIS: IN1.W2
3 DIS: IN1.W3
4 DIS: IN2.W1
CAN-IN2
5 DIS: IN2.W2
6 DIS: IN2.W3
7 DIS: IN2.W4
8 DIS: IN3.W1
CAN-IN3
9 DIS: IN3.W2
10 DIS: IN3.W3
11 DIS: IN3.W4
C0867 -2147483648 {1} 2147483647
32-bit phase signal, function
block CAN-IN
z Read only
z 1 rev. = 65536
1 DIS: IN1.D1
2 DIS: IN2.D1
3 DIS: IN3.D1
C0868 -199.99 {0.01 %} 199.99
Process output words, function
block CAN-OUT
z Display of the signals linked in
C0860
z 100% = 16384
See System
Manual
(extension)
1 DIS: OUT1.W1
2 DIS: OUT1.W2
3 DIS: OUT1.W3
4 DIS: OUT2.W1
5 DIS: OUT2.W2
6 DIS: OUT2.W3
7 DIS: OUT2.W4
8 DIS: OUT3.W1
9 DIS: OUT3.W2
10 DIS: OUT3.W3
11 DIS: OUT3.W4
C0869 -2147483648 {1} 2147483647
32-bit phase information,
function block CAN-OUT
z Display of the signals linked in
C0861
z 1 rev. = 65536
1 DIS: OUT1.D1
2 DIS: OUT2.D1
3 DIS: OUT3.D1
