Code InfoPossible settingsLCDCode Info
SelectionLenze
LCD
C0867 DIS: Inx.D1
g
System bus: Process input double words
-2147483648 {1} 2147483647
1 CAN1_IN: Process i nput double word 1
(CAN1_dnInD1_p)
2 CAN2_IN: Process i nput double word 1
(CAN2_dnInD1_p)
3 CAN3_IN: Process i nput double word 1
(CAN3_dnInD1_p)
C0868 DIS: OUTx.Wx
g
System bus: Process output words
-32768 {1 %} 32767
1 CAN1_nOutW1_a
2 CAN1_nOutW2_a
3 CAN1_nOutW3_a
4 CAN2_nOutW1_a
5 CAN2_nOutW2_a
6 CAN2_nOutW3_a
7 CAN2_nOutW4_a
8 CAN3_nOutW1_a
9 CAN3_nOutW2_a
10 CAN3_nOutW3_a
11 CAN3_nOutW4_a
C0869 DIS: Out1/2.Dx
g
System bus: Process output double words
-2147483648 {1} 2147483647
1 CAN1_OUT: Process output double word 1
(CAN1_dnOutD1_p)
2 CAN2_OUT: Process output double word 1
(CAN2_dnOutD1_p)
3 CAN3_OUT: Process input double word 1
(CAN3_dnOutD1_p)
C0878 DigInOfDctrl g DCTRL_DriveControl: Digital inputs
01
1 DCTRL_bCInh1_b
2 DCTRL_bCInh1_b
3 DCTRL_bTripSet_b
4 DCTRL_bTripReset_b
C0879 Reset ctrl Resetofcontrolwords
• C0879/x = 1 performs 1 reset.
0Donotreset
1 Reset
1 C0135
2 AIF
3 CAN
