9300 Servo PLC
Appendix
3-32
L
ServoPLC EN 2.0
Code InfoPossible settingsLCDCode Info
SelectionLenze
LCD
C0858 DIS: OUT.Wx
g
Automation interface (AIF): Process output words
-32768 {1 %} 32767
1 AIF1_OUT: Process output word 2 (AIF1_nOutW1_a)
2 AIF1_OUT: Process output word 3 (AIF1_nOutW2_a)
3 AIF1_OUT: Process output word 4 (AIF1_nOutW3_a)
C0859 DIS: OUT.D1
g
Automation interface (AIF): Process output word
• AIF1_dnOutD1_p (32 bit angle information)
-2147483648 {1} 2147483647
C0863 DIS: INx dig x
g
System bus: Process input words
0000 {hex} FFFF
Hexadecimal value is bit coded:
1 Bit 00 CAN1_bInB0_b
Bit 01 CAN1_bInB1_b
...
Bit 15 CAN1_bInB15_b
CAN1_IN: Process input word 1
2 Bit 00 CAN1_bInB16_b
Bit 01 CAN1_bInB17_b
...
Bit 15 CAN1_bInB31_b
CAN1_IN: Process input word 2
3 Bit 00 CAN2_bInB0_b
Bit 01 CAN2_bInB1_b
...
Bit 15 CAN2_bInB15_b
CAN2_IN: Process input word 1
4 Bit 00 CAN2_bInB16_b
Bit 01 CAN2_bInB17_b
...
Bit 15 CAN2_bInB31_b
CAN2_IN: Process input word 2
5 Bit 00 CAN3_bInB0_b
Bit 01 CAN3_bInB1_b
...
Bit 15 CAN3_bInB15_b
CAN3_IN: Process input word 1
6 Bit 00 CAN3_bInB16_b
Bit 01 CAN3_bInB17_b
...
Bit 15 CAN3_bInB31_b
CAN3_IN: Process input word 2
C0866 DIS: INx.Wx
g
System bus: Process input words
-32768 {1 %} 32767
1 CAN1_nInW1_a
2 CAN1_nInW2_a
3 CAN1_nInW3_a
4 CAN2_nInW1_a
5 CAN2_nInW2_a
6 CAN2_nInW3_a
7 CAN2_nInW4_a
8 CAN3_nInW1_a
9 CAN3_nInW2_a
10 CAN3_nInW3_a
11 CAN3_nInW4_a
