Lenze Global Drive 9300 Servo PLC Series User Manual

9300 Servo PLC
Appendix
3-31
L
ServoPLC EN 2.0
Code InfoPossible settingsLCDCode Info
SelectionLenze
LCD
C0593 MONIT CE3 3 System bus: Monitoring configuration
CAN3_IN communication error (CE3)
0TRIP
2 Warning
3Off
C0594 MONIT SD6 à Monitori ng configuration: Motor temperature sensor error
(X7 or X8)
à depending on C0086
0TRIP
2 Warning
3Off
C0595 MONIT CE4 3 System bus: Monitoring configuration
“BusOffState” (CE4)
0TRIP
2 Warning
3Off
C0596 NMAX limit 5500 Monitoring configuration: Max. machine speed
0 {1 rpm} 16000
C0598 MONIT SD5 3 Monitoring configuratio: Master current at X6/1, 2
(Master current < 2 mA)
0TRIP
2 Warning
3Off
C0608 ovr Tx-Queue 0 System bus: Monitoring configuration
Free CAN objects: Tx buffer (send memory overflow)
0TRIP
1 Message
2 Warning
3Off
4FailQSP
C0609 over Rx-lsr 0 System bus: Monitoring configuration
Free CAN objects: Too many receive telegrams
0TRIP
4FailQSP
C0855 DIS: IN (0-15)
g
Automation interface (AIF): Process input words
0000 {hex} FFFF
Hexadecimal value is bit coded:
1 Bit 00 AIF1_bInB0_b
Bit 01 AIF1_bInB1_b
...
Bit 15 AIF1_bInB15_b
AIF1_IN: Process input word 3
2 Bit 00 AIF1_bInB16_b
Bit 01 AIF1_bInB17_b
...
Bit 15 AIF1_bInB31_b
AIF1_IN: Process input word 4
C0856 DIS: IN.Wx
g
Automation interface (AIF): Process input words
-32768 {1 %} 32767
1 AIF1_IN: Process input word 2 (AIF1_nInW1_a)
2 AIF1_IN: Process input word 3 (AIF1_nInW2_a)
3 AIF1_IN: Process input word 4 (AIF1_nInW3_a)
C0857 DIS: IN.D1
g
Automation interface (AIF): Process input word
• AIF1_dnInD1_p (32 bit angle information)
-2147483648 {1} 2147483647
