9300 Servo PLC
Appendix
3-35
L
ServoPLC EN 2.0
Code InfoPossible settingsLCDCode Info
SelectionLenze
LCD
C1190 Char.: temp 1 0 PTC: Type selection for motor
0 Lenze standard
1 User-specific
C1191 Char.: temp PTC: Temperature characteristic selection
0 {1 °C} 255
1 100 Characteristic for temperature 1
2 150 Characteristic for temperature 2
C1192 Char.: OHM PTC: Resistance characteristic selection
0{1Ω} 30000
1 1670 Characteristic for R1 at temperature 1
2 2225 Characteristic for R2 at temperature 2
C1799 DFOUT fmax 1250 DF_OUT_DigitalFrequency:
Maximum output frequency at X10
20 {1 kHz} 1250
C1810 S/W Id keypad
g
Keypad identification
C1811 S/W date keypad
g
Keypad creation date
C2100 Time slice 13 Time slice for task switch between system task and cyclic
task (PLC_PRG)
6{1msec}26
C2102 Task switch 0 Configuration of task switch process
Activation after:
0 Time slice
1 Time slice + end PLC_PRG
2 Time slice + end PLC_PRG + end system task
C2104 PLC Autorun 0 Automatic start of the PLC program after power switch-on
0Noautostart
1 Auto start after mains connection
C2106 Downl.protect 0 Write protection for the PLC program
0 No new download possible
1 New download possi ble
C2108 PLC run/stop 0 PLC program
0 No function
1PLCrun
2 PLC stop
3PLCreset
start
stop
reset
C2111 GDC Id
g
Compile time/PLC program date
C2113 PLC Prog Name
g
Name of the PLC program
C2115 T-Fkt Credit
g
Technology units
C2117 Full credit
g
Service code
C2118 ParWriteChan. 0 CAN object for L_ParRead and L_ParWrite
0 PDO channel (CAN1_IO ... CAN3_IO)
1 SDO2 channel
C2120 AIF: Control AIF command
0 No command
1 Read CAN code + new initialisation
2 Read XCAN code
10 Read XCAN C2356/1..4
11 Read XCAN C2357
12 Read XCAN C2375
13 Read XCAN C2376 ... C2378
14 Read XCAN C2382
15 Not assigned
