Terminal data
Inverter I55AExxxx
Inverter kW 0.25 ... 0.75 1.1 ... 2.2 4.0 ... 5.5 0.25 ... 5.5 0.25 ... 2.2 4.0 ... 5.5
Connecon Mains connecon X100 PE connecon Motor connecon X105
Connecon type Pluggable screw terminal Screw
terminal
PE screw Pluggable
screw
terminal
Screw
terminal
Max. cable cross-secon mm² 2.5 6 6 6 2.5 6
Stripping length mm 8 8 9 10 8 9
Tightening torque Nm 0.5 0.7 0.5 2 0.5 0.5
Required tool 0.5 x 3.0 0.6 x 3.5 Torx 20 0.5 x 3.0 0.6 x 3.5
Fusing data
EN 60204-1
Inverter Fuse Circuit breaker Earth-leakage circuit
breaker
Characterisc Max. rated
current
Characterisc Max. rated
current
A A
I55AE125D gG/gL or gRL 10 B 10 ≥ 30 mA, type B
I55AE137D gG/gL or gRL 10 B 10 ≥ 30 mA, type B
I55AE155D gG/gL or gRL 16 B 16 ≥ 30 mA, type B
I55AE175D gG/gL or gRL 16 B 16 ≥ 30 mA, type B
I55AE211D gG/gL or gRL 25 B 25 ≥ 30 mA, type B
I55AE215D gG/gL or gRL 25 B 25 ≥ 30 mA, type B
I55AE222D gG/gL or gRL 25 B 25 ≥ 30 mA, type B
I55AE240C gG/gL or gRL 32 B 32 ≥ 300 mA, type B
I55AE255C gG/gL or gRL 32 B 32 ≥ 300 mA, type B
3-phase mains connecon 230/240 V "Light Duty"
Connecon diagrams
See "3-phase mains connecon 230/240 V". ^ 158
Terminal data
Inverter I55AExxxx
Inverter kW 5.5 ... 7.5 5.5 ... 7.5 5.5 ... 7.5
Connecon Mains connecon X100 PE connecon Motor connecon X105
Connecon type Screw terminal PE screw Screw terminal
Max. cable cross-secon mm² 6 6 6
Stripping length mm 9 10 9
Tightening torque Nm 0.5 2 0.5
Required tool 0.6 x 3.5 Torx 20 0.6 x 3.5
Fusing data
EN 60204-1
Inverter Fuse Circuit breaker Earth-leakage circuit
breaker
Characterisc Max. rated
current
Characterisc Max. rated
current
A A
I55AE240C gG/gL or gRL 32 B 32 ≥ 300 mA, type B
I55AE255C gG/gL or gRL 32 B 32 ≥ 300 mA, type B
Electrical
installaon
Mains connecon
3-phase mains connecon 230/240 V "Light Duty"
