Lenze i550 Series - IO-Link

IO-Link
Typical topologies
Tree
M
Dn
D2
D1
M Master D Device
Link-related informaon
Name IO-Link
Specicaon 1.1
Baud rate 230.4 kbaud (COM 3)
Cycle
me 2 ms
Port Class A (type A) I max. 200 mA
Connecon designaon
L-
C/Q
L+
X316
IO-Link
L+ 24 V
C/Q Switching and communicaon line
L- 0 V
Connecon
descripon IO-Link
Connecon X316
Connecon type pluggable double spring terminal
Max. cable cross-secon mm² 2.5
Max. cable cross-secon AWG 12
Stripping length mm 10
Stripping length inch 0.39
Tightening torque Nm -
Tightening torque lb-in -
Required tool 0.4 x 2.5
Status display
The LEDs indicate the connecon status to the network:
LED "RUN" (green) Status/meaning
O No data transfer.
Blinking
Acve data transfer.
Electrical installaon
Networks
IO-Link
181
