Lenze L-force 9400 Hardware Manual

Multi−axis controllers
Rated data
Overview
4

172
EDS94SPP101 EN 10.2
4.4 Rated data
The E94AMxExxx4 devices can be used in the voltage range of 260 ... 746 V DC.
 Note!
To ensure a faultless operation of the devices the code C00173 must be set
according to the mains voltage connected.
Emergency operation
Operation of the E94AMxxxx4 devices with an emergency voltage supply at +UG, −UG, is
possible with V
DC
 260 V. The settings in C00173 and C00174 are to be adapted
accordingly. A 24−V supply at X2 is required.
4.4.1 Overview
Input data
Voltage Frequency Rated current [A]
Number of
phases
[V] [Hz] up to +45 °C  up to +55 °C 
E94AMxE0024 325/565/675 0 ( DC) 2.6/2.6/2.3 2.0/2.0/1.7 −
E94AMxE0034 325/565/675 0 ( DC) 4.3/4.3/3.8 3.2/3.2/2.9 −
E94AMxE0044 325/565/675 0 ( DC) 6.7/6.7/5.9 5.0/5.0/4.4 −
E94AMxE0074 325/565/675 0 ( DC) 12.1/12.1/10.6 9.1/9.1/8.0 −
E94AMxE0094 325/565/675 0 ( DC) 15.4/15.4/13.5 11.6/11.6/10.1 −
E94AMxE0134 325/565/675 0 ( DC) 20.6/20.6/18.0 15.5/15.5/13.5 −
E94AMxE0174 325/565/675 0 ( DC) 25.7/25.7/22.5 19.3/19.3/16.9 −
E94AMxE0244 325/565/675 0 ( DC) 35.5/35.5/31.1 26.3/26.3/23.3 −
E94AMxE0324 325/565/675 0 ( DC) 48.0/48.0/38.9 36.0/36.0/29.1 −
E94AMHE0474 325/565/675 0 ( DC) 71.0/71.0/62.0 53.3/53.3/46.5 −
E94AMHE0594 325/565/675 0 ( DC) 89.0/89.0/77.0 66.8/66.8/57.8 −
 Temperature in the control cabinet
Output data
Voltage Frequency Current [A]
Number of
phases
Type [V] [Hz] up to +45 °C

up to +55 °C

E94AMxE0024 0 − 230/400/480 0 − 599 1.5/1.5/1.3 1.1/1.1/1.0 3
E94AMxE0034 0 − 230/400/480 0 − 599 2.5/2.5/2.2 1.9/1.9/1.7 3
E94AMxE0044 0 − 230/400/480 0 − 599 4/4/3.5 3/3/2.6 3
E94AMxE0074 0 − 230/400/480 0 − 599 7/7/6.1 5.3/5.3/4.6 3
E94AMxE0094 0 − 230/400/480 0 − 599 9.3/9.3/8.2 7.0/7.0/6.2 3
E94AMxE0134 0 − 230/400/480 0 − 599 13/13/11.4 9.8/9.8/8.6 3
E94AMxE0174 0 − 230/400/480 0 − 599 16.5/16.5/14.4 12.4/12.4/10.8 3
E94AMxE0244 0 − 230/400/480 0 − 599 23.5/23.5/20.6 17.6/17.6/15.5 3
E94AMxE0324 0 − 230/400/480 0 − 599 32.0/32.0/25.9 24.0/24.0/19.4 3
E94AMHE0474 0 − 230/400/480 0 − 599 47.0/47.0/42.0 35.3/35.3/30.8 3
E94AMHE0594 0 − 230/400/480 0 − 599 59.0/59.0/52.0 44.3/44.3/38.7 3
 Temperature in the control cabinet
